型號Model
|
TKB800
|
|
| 手腕負載Payload | 6kg | |
| 最大工作半徑Max Working Radius | 876mm | |
| 自由度DOF | 4軸 | |
| 本體重量Body Weight | 26kg | |
| 減速機品牌Reducer Brand | 進口 | |
| 電機品牌Motor Brand | 進口 | |
| 驅動品牌Drive Brand | 進口 | |
| 額定功率Rated Power | 1.2kw | |
| 關節速度Max Speed | J1 | 300°/s |
| J2 | 300°/s | |
| J3 | 320°/s | |
| J4 | 380°/s | |
| 關節范圍Max Operation Area | J1 | ±170° |
| J2 | 135°~-70° | |
| J3 | 255°~-75° | |
| J4 | ±130° | |
| 防護等級protective specification | IP54 | |
| 重復定位精度Position Repeat Accuracy | ±0.08mm | |
| 控制柜controller | TRC3-A06 | |
| 工作溫度Working Temperature | 0~45℃ | |
